GeoVision GV-TBL8804 8MP Super Low Lux WDR Full Color IP Camera 8MP IP67

GV-TBL8804

AI 8MP H.265 Super Low Lux WDR Pro Full Color Warm LED IR Bullet IP Camera

AI Deep-Learning IP Camera

The Bullet IP Camera is an outdoor, network camera equipped with an automatic IR-cut filter, one IR LED, and two warm LEDs for day and night surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. GV-TBL8804 adheres to IP67 standards, and can be powered through PoE.

GV-TBL8804 is a camera for active deterrence. By using built-in warm LEDs and alarm sound, it can deter intruders and prevent potential crime.

Empowered by deep learning algorithms, AI technology distinguishes human and vehicles from other moving objects. Integrated with GeoVision Video Management Software (VMS), it supports AI perimeter protection, real time alert, events playback and more.

Features:

• Model Number: GV-TBL8804
•  AI deep learning: AI Perimeter Protection & Classification (Human, Vehicle)
• 1/2.7" progressive scan super low lux CMOS sensor
• Triple streams from H.265, H.264 or MJPEG
• Wide Dynamic Range Pro (WDR Pro)
• Min. illumination at 0.01 lux
• Up to 20 fps at 3480 x 2160
• Intelligent IR
• Day and night function (with removable IR-cut filter)
• Active Deterrence: alarm sound and warm LED light triggered on AI detection events
• IR distance up to 30 m (100 ft)
• Ingress protection (IP67)
• Built-in micro SD card slot (SD / SDHC / SDXC / UHS-I, Class 10) for local storage
• Built-in microphone and speaker
• Two-way audio
• DC 12V / PoE (IEEE 802.3af)
• ONVIF (Profile S, G, T) conformant

Specifications

Camera

• Image Sensor - 1/2.7" progressive scan super low lux CMOS
• Picture Elements - 3840 (H) x 2160 (V)
• Minimum illumination- Color - 0.01 Lux, (F2.0, AGC ON), IR ON - 0 Lux
• Shutter Speed - Auto / Manual (1 ~ 1/100000 sec)
• White Balance - Auto / Manual
• Gain Control - Auto / Manual
• S/N Ratio - 55 dB
• WDR - WDR Pro
• Dynamic Range - 120 dB

Lens

• Megapixel - 8 MP
• Focal Length - 4 mm
• Day/Night - Yes (with removable IR-Cut Filter)
• Lens Type - Fixed Lens
• Maximum Aperature - F/2.0
• Mount - M12
• Horizontal FOV - 86°
• Operation - Focus: Fixed, Zoom: Fixed, Iris: Fixed
• IR LED Quantity - 1 IR LED
• Max. IR Distance - 30 m (100 ft)
• Warm LED Quantity - 2 warm LEDS
• Max. Warm LED Light Distance - 20 m (65ft)

Operation

• Video Compression - H.265, H.264, MJPEG
• Video Streaming - Triple streams from H.265, H.264 or MJPEG
• Frame Rate - 20 fps at 3840 x2160, 25 fps at 2944 x 1656 / 2560 x 1440, 30 fps at 1920 x 1080 (60 /50 Hz)
• Video Analytics - Motion Detection, Tampering Alarm, Audio Detection, *Tampering alarm, Audio detection are only accessible through the camera?s Web interface, which can be used to trigger alerts such as e?mail and FTP
• Image Setting - Brightness, Contrast, Saturation, Sharpness, Flicker?less, 3D Noise Reduction, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270°?including Corridor format)
• Audio Compression - G.711
• Audio Support - Two-way Audio (built-in microphone and speaker)

Deep Learning Function

• AI Analytics:
• Intrusion, Crossing Line, Entering Area, Leaving Area (Human & Vehicle classification), Face Detection, People Flow Counting, Crowd Density Monitoring

Video Resolution

• Main Stream- 3840 x 2160 (Default), 2944 x 1656, 2560 x 1440, 1920 x 1080
• Sub Stream- 1280 x 720, 704 x 576, 704 x 288, 640 x 360 (Default), 352 x 288
• Third Stream (Closed by Default) -704 x 576, 704 x 288, 640 x 360, 352 x 288

Network

• Interface - 10/100 Ethernet
• Protocol - 802.1x, ARP, DHCP, DDNS, DNS, DynDNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTCP, RTP, RTSP, SMTP, SNMP, TCP, UDP, UPnP, ONVIF (Profile S, G, T)

Mechanical

• Camera Angle Adjustment
  • Pan - 0° ~ 360°
  • Tilt - 0° ~ 900°
  • Rotate - 0° ~ 360°
• Connectors- Power: DC Jack (DV 12V, 1.25A), PoE, Audio: 1 In (built?in microphone), Local Storage: Micro SD card slot (SD / SDHC / SDXC / UHS?I, Class 10), Ethernet: RJ?45

General

• Environment Temperature - ?22°F ~ 140°F
• Humidity - 0% to 95% (no condensation)
• Power Source - 12V DC / PoE (IEEE 802.3af)
• Max. Power Consumption - 10.5 W
• Weight - 0.99 lb
• Dimensions - 7.4" x 2.8" x 2.8"
• Ingress Protection - IP67
• Regulatory - CE, FCC, RoHs, UL compliant

Web Interface

• Installation Management - Web?based configuration
• Maintenance - Firmware upgrade through Web Browser or GV?IP Device Utility
• Access from Web Browser - Live View, Video Recording, Change Video Quality, Bandwidth Control, Image Snapshot, Defog, Text Overlay, Image Masking
• Language - Czech, English, French, German, Italian, Russian, Traditional Chinese

Software Applications

• Software Supported - GV?VMS (V17.4.1 / V18.2.1), GV?DVR / NVR (V8.9.1), GV?Control Center (V3.8.0), GV?Recording Server / Video Gateway (V2.0.0), GV?Edge Recording Manager Win version (V2.0.0), GV?Redundant / Failover Server (V1.2.0)
• Smart Device Access - GV?Eye for iOS and Android
• Live Viewing - Browser (IE, Chrome, Edge), Mobile App
